lattice telecom tower is Junjiang's first product that was delivered to another country. Our lattice telecom tower factory manufactures various telecom tower types including 3/4 legs angular steel tower and tubular steel tower, monopole tower and guyed cell tower, tower base transceiver station, etc. All of them are processed following the national processing standard, and all components are hot-dip galvanized or painted as request. Factory test report and certificate of product quality will be released before delivery. With our quality lattice tower telecom, the local's living standard will be improved significantly. For more infomation about our metal pole fittings, contact us now!
Different types of telecom towers
3-legged Communication Tower
Height: As per request
Material: Q355B (Yeild Strength≥345MPa) & Q235B (Yeild Strength≥235MPa)or A36/A572 Gr50/S355JR
Design standard: GB / ANSI / TIA-222-G/BS 8100
Surface treatment: Hot-dip galvanized/Painting/Powder coating
Antenna Type: GSM, RRU,CDMA, MW etc.
Galvanization Standard: GB/T 13912-2002, EN ISO 1461,ASTM/A123
Angular Steel Tower
Height: Up to 100m
Type: 3/4 legs
Material: Q355B(Yeild Strength≥345MPa)& Q235B (Yeild Strength≥235MPa) or ASTM572,GR65,GR50,SS400
Design standard: GB / ANSI / TIA-222-G/BS 8100
Surface treatment: Hot dip galvanized/Painting
Antenna Type: GSM, RRU,CDMA, MW etc.
Galvanization Standard: GB/T 13912-2002, EN ISO 1461,ASTM/A123
Monopole Tower
Shape：Polygonal (6-18 sides)
Material：Q355B & Q235B or A36/A572 Gr50/S355JR
Design Standard：GB / ANSI / TIA-222-G/ BS 8100
Foundation Type：Independent Foundation / Raft Foundation / Pile Foundation
Antenna Type：GSM, RRU,CDMA, MW etc.
Connection of sections：Overlap / Flange connection
Welding Standard：AWSD1.1
Surface treatment：Hot dip galvanized/Painting/Spray
Galvanization Standard: GB/T 13912-2002, EN ISO 1461,ASTM/A123
Guyed Tower
Height: As per request
Material: Q235B, 50*4-60*4 or equivalent
Design standard: GB / ANSI / TIA-222-G/ BS 8100
Basic Wind speed: 180km/h_3 second gust or as per design
Antenna Type：GSM, RRU,CDMA, MW etc.
Surface treatment：Hot dip galvanized/Painting/Spray
Galvanization Standard: GB/T 13912-2002, EN ISO 1461,ASTM/A123
Welding Standard: AWSD1.1
Camouflaged Tower
Material: Q355B & Q235B or A36/A572 Gr50/S355JR
Basic Wind speed: 160km/h_3 second gust or as per design
Leaf Type: Pine, coconut palm, and banyan tress or as request
Quantity of platform: As per request
Surface treatment: Hot dip galvanized and simulated tree bark
Design standard: GB / ANSI / TIA-222-G/ BS 8100
Anti-seismic Grade: 8
Welding Standard: AWSD1.1
Rooftop Telecom Tower
Material: Q355B & Q235B or A36/A572 Gr50/S355JR
Antenna Type: GSM, RRU,CDMA, MW etc.
Design standard: GB / ANSI / TIA-222-G/ BS 8100
Surface treatment: Hot dip galvanized/Painting/Spray
Galvanization Standard: GB/T 13912-2002, EN ISO 1461,ASTM/A123
Welding Standard: AWSD1.1
Tower Base Transceiver Station
Height: 30 m or as request
Quantity of platform: 2
Quantity of antennas: 3 sets for each platform, 6 in total
Quantity of bracket: 6
Roof and wall: PU with excellent thermal insulation, strength, and stability (density greater than 30kg per cubic meter)
Core material: Fireproof core material
Keel Steel: keel
Thickness of wall and roof: ≥100 mm
Read More +
How Does a Telecommunication Tower Work?
A telecommunication tower, often called a cell tower or radio tower, is a critical infrastructure for modern communication. It functions by supporting antennas that transmit and receive radio frequency signals. These signals facilitate wireless communication for mobile phones, internet services, and broadcasting. The tower connects to a network of base stations, which process and route the signals to ensure seamless communication. Power supply and backup systems ensure continuous operation, while advanced technology like 5G enhances speed and connectivity. In essence, tower of telecommunications are the backbone of our wireless communication networks, enabling instant and reliable connectivity. Junjiang Construction, one of top steel tower manufacturers, offers high quality telecommunication tower at a competitive price.
What Are the Components of telecom lattice tower?
Antenna Systems
These are crucial for transmitting and receiving signals, enabling wireless communication for mobile phones, internet, and broadcasting services.
Structural Framework
The tower's steel or aluminum structure provides the necessary height and stability to support antennas and other equipment.
Power Supply Units
These include backup generators and batteries to ensure continuous operation, even during power outages, maintaining uninterrupted communication.
Cabling and Connectors
Essential for linking antennas to base stations and other network components, ensuring efficient signal transmission and reception.
For more information about tower types in telecom and steel tower in china, please feel free to contact us!
